Duo-eVap 96 Well plate Nitrogen Evaporator

With enhancement in technology, several Diagnostic and R&D labs prefer the 96 well plate format for processing samples. To meet this requirement, Takahe Analytical Instruments introduced the DRY 96 Well plate Nitrogen evaporator and have met great success. Available in both Open and Closed formats Duo-eVap and SpeedoVap 96 respectively, both use dry heated gas for evaporation.

Duo-eVap: Well plate evaporator – Suitable for various well plate formats from 24 to 384 well microplates, this dry evaporator meets the ever changing needs of laboratories.

Duo-eVap and Duo-eVap Dual designed and developed at our facilities to keep up with the change in technology and diagnostics.

Available for single, dual well-plates and also can be configured for test tubes, this is a dry evaporation process and is achieved by passing heated gas from the top as well as below each well / tube.

The well-plates can be adjusted to any height to accommodate 24,48,96, 384 well plate or test tubes of different volumes.

Gas and temperature controls are on the front panel for simple setting and high visibility. The gas manifold head and well plate bay can be easily removed for cleaning. The gas needles are removable and can be sonicated or replaced as required.

Technical Specifications

Technology Dry evaporation - Blowdown
Capacity One or 2 Well plates (Dual Duo-eVap)
Well plate format 24, 48, 96, 384 / Test tube
Well plate Bay One included as per requirement (Two for Dual Duo-eVap)
Heating Heated Nitrogen
Operating Temperature

Max 60⁰C (upper)

Max 75⁰C (Lower)

Gas Supply Requirements Min. inlet pressure 60 psi, Max. inlet pressure 100 psi
Operating Flow rate 20-100 lpm X 2
Gas control Single input
Power Requirements 230 VAC at 50 Hz
Dimensions (WxDxH) 9.25" x 17.0"x 23.0" ( 23.5 x 43.0 x 58.5 )
Net Weight 25 kg
Shipping Weight 35 kg
