Min-eVap Nitrogen Evaporator

Min-eVAP is a Low Volume Nitrogen Evaporator, used commonly in labs having a low work load and fixed requirement.

Bearing all the features of the SpeedoVap LV, the Min-eVap is a mini nitrogen evaporator that offers the convenience of low volume sample evaporation at low cost. It is an efficient new alternative to conventional evaporation techniques giving uniform results with a fast turn-around time. This mini evaporator is designed to occupy very small table space and small tank to quickly reach set temperatures for evaporation. The system has the facility to use interchangeable racks for different types of tubes with different sample volumes (1.5 mL to 15 mL and Ria vials/test tube/centrifuge tubes).

A micro-processor control maintains the water-bath at the set temperature and the times for the operation. Gas can be turned ON in selected manifolds depending on number of samples. Nitrogen gas is blown through nozzle manifolds into samples which turn OFF automatically after process is completed. Besides other process and service alarms, the audio alarms indicate when the process is complete.

Min-eVAP is used in small testing labs and education institutions. Food industries doing inhouse audits for their samples find great value with the Min-eVAP to evaporate solvents in analysis of antibiotics , phenolics and other pesticide extracts. It is ideal for sample volumes upto 15 mL using Eppendorf tubes, Ria vials or Tarson centrifuge tubes.


  • Unattended operation for up to 15 samples.
  • Different interchangeable racks available for tube sizes from 1.5 mL to 15 mL.
  • Controlled water bath adjustable from ambient to 80 °C.
  • Built-in nitrogen regulator.
  • LED display for better visibility under fume hood.
  • Convenient size—no hood space required.
  • Exhaust open to atmosphere or within Fume Hood.
  • Easy to use water drain pump.
  • Alarms for various processes to draw attention of the user.
  • Small foot print.

Technical Specifications

Maximum Number of Samples 15
Max. sample volume 15 mL
Rack Supplied Any one rack listed
Water Bath Temperature Ambient to 80 °C. (Up to 90°C if needed)
Timer Range 1 min to 9.50 hours/indefinite
Gas Supply Requirements Inlet pressure 100 psi
Gas control Gas can be turned ‘ON’ for any / each of five independent manifolds
Gas Regulator and Gas Gauge Range Provided – manually adjustable.
Gas Flow required 45 LPM
Exhaust In-built , Duct hose provided
Power Requirements 230 VAC at 50 Hz
Dimensions (WxDxH) 15.75” X 14.2” X 11” (40 X 36 X 28 cms)
Net Weight 9.5 kg
Shipping Weight 15 kg
Technology Sample Vortexing

2004/22/EC Measuring Instruments Directive

2014/35/EU Low Voltage Directive

2009/105/EC Simple Pressure Vessels

Racks available for the following test tube sizes

Test Tubes
2 mL Flip/screw cap micro-centrifuge tubes/Eppendorf tubes
3 mL 10 X 75
4 mL 12 X 75 / Ria Vials
4 mL 14 x 45 Screw Top Vial
12 mL 16 X 100
15 mL 17 X 125
