Takahe Nitrogen Evaporator SpeedoVap Dry Block

Clinical Research

SpeedoVap Dry Block Nitrogen Evaporator

Few laboratories choose to use DRY HEAT to evaporate samples. With low chances of contamination this model is often the choice for sample evaporation.

Technical Specifications

Maximum Number of Samples 15
Max. Sample Volume 15 mL
Rack Supplied One block for any one test tube size (options – Eppendorf, Ria vial, Tarson Centrifuge tube)
Heat Block Ambient to 80°C.
Timer Range 1 min to 9 hours 50 mins hours/indefinite
Gas Supply Requirements

Min. inlet pressure 70 psi

Max. inlet pressure 100 psi

Gas can be turned ‘ON’ for any/ each of three independent manifolds

Gas Regulator and Gas Gauge Range Provided – manually adjustable.
Gas Flow required 45 LPM
Exhaust In-built , 1 m Duct hose provided
Power Requirements 230 VAC at 50 Hz
Net Weight 18 kg
Shipping Weight 25 kg

2004/22/EC Measuring Instruments Directive,

2014/35/EU Low Voltage Directive

2009/105/EC Simple Pressure Vessels.
