Takahe Nitrogen Evaporator SpeedoVap Dry Block
Few laboratories choose to use DRY HEAT to evaporate samples. With low chances of contamination this model is often the choice for sample evaporation.
| Maximum Number of Samples | 15 |
| Max. Sample Volume | 15 mL |
| Rack Supplied | One block for any one test tube size (options – Eppendorf, Ria vial, Tarson Centrifuge tube) |
| Heat Block | Ambient to 80°C. |
| Timer Range | 1 min to 9 hours 50 mins hours/indefinite |
| Gas Supply Requirements |
Min. inlet pressure 70 psi Max. inlet pressure 100 psi Gas can be turned ‘ON’ for any/ each of three independent manifolds |
| Gas Regulator and Gas Gauge Range | Provided – manually adjustable. |
| Gas Flow required | 45 LPM |
| Exhaust | In-built , 1 m Duct hose provided |
| Power Requirements | 230 VAC at 50 Hz |
| Net Weight | 18 kg |
| Shipping Weight | 25 kg |
| Certifications |
2004/22/EC Measuring Instruments Directive, 2014/35/EU Low Voltage Directive 2009/105/EC Simple Pressure Vessels. |
