Takahe Nitrogen Evaporator SpeedoVap LX


SpeedoVap LX Nitrogen Evaporator

Several users do not require the high end features found in most evaporators. To meet the demand of small testing labs, we offer a low cost Nitrogen evaporator with basic functions at budget price. The main features of the evaporator are retained.

Technical Specifications

Maximum Number of Samples 30/50
Max. sample volume 30 mL
Rack Supplied Any one Rack listed based on requirement. (optional additional racks can be ordered separately)
Water Bath Temperature Ambient to 80 °C.
Timer Range 1 min to 10 hours/indefinite
Gas Supply Requirements

Min. inlet pressure 70 psi

Max. inlet pressure 100 psi

Gas can be turned ‘ON’ for any/ each of three independent manifolds

Gas Regulator and Gas Gauge Range Provided – manually adjustable.
Gas Flow Required 90 Lpm/150 Lpm
Exhaust In-built ,1 m Duct hose provided
Power Requirements 230 VAC at 50 Hz
Net Weight 18 kg
Shipping Weight 25 kg

2004/22/EC Measuring Instruments Directive,

2014/35/EU Low Voltage Directive

2009/105/EC Simple Pressure Vessels.
