Takahe Nitrogen Evaporator SpeedoVap 96WP


SpeedoVap 96WP Well plate Nitrogen Evaporator

With changing demands in the laboratory and some projects requiring to process ultra-low sample sample volume, we have on offer the SpeedoVap 96WP (96 Well-plate) Nitrogen Evaporator.

An alternative to the water-bath evaporator, the 96 well-plate evaporator uses heated dry air to evaporate the solvent.

This is a closed hood well-plate evaporator uses a micro-processor to control and maintain the dry-block well-plate bay . The nozzles are directed into the wells for drying. Temperature and time are set for the operation. The Nitrogen gas that is blown through nozzle manifolds into samples turn OFF automatically after process is completed. Besides other process and service alarms, the audio alarms indicate when the process is complete.

Used in diagnostic labs and research involving low volumes, the SpeedoVap 96 Well-plate evaporator is a useful addition to testing labs.


  • Unattended operation.
  • Can be made for well-plate for 1000μL and 2000μL.
  • Controlled heated block adjustable from ambient to 70 °C.
  • Built-in nitrogen regulator.
  • LED display for better visibility under fume hood.
  • Convenient size—no hood space required.
  • Exhaust open to atmosphere or within Fume Hood.
  • Alarms for various processes to draw attention of the user.
  • Small foot print.

Technical Specifications

Maximum Number of Samples 96
Well-plate Bay Supplied One Well-plate
Dry Block Temperature Ambient to 70 °C.
Timer Range 1 min to 9.50 hours/indefinite
Gas Supply Requirements Inlet pressure 100 psi
Gas control Gas can be turned ‘ON’ for any / each of s
Gas Regulator and Gas Gauge Range Provided – manually adjustable.
Gas Flow required 170 LPM
Exhaust In-built , Duct hose provided
Power Requirements 230 VAC at 50 Hz
Dimensions (WxDxH) 15.75” X 14.2” X 11” (40 X 36 X 28 cms)
Net Weight 9.5 kg
Shipping Weight 15 kg
Technology Sample Vortexing

2004/22/EC Measuring Instruments Directive,

2014/35/EU Low Voltage Directive

2009/105/EC Simple Pressure Vessels.
