Nitrogen Generator N2 Genie

Takahe Nitrogen Generator N2 Genie


N2 Genie Nitrogen Generator

Nitrogen Generator

A Nitrogen generator produces nitrogen gas from compressed air. Nitrogen is a colorless gas that makes up 78% of the Earth's atmosphere. It is non-flammable and non-reactive, making it an ideal gas for many industrial and commercial applications. Productive time of analysts and users spent in follow-up for cylinder procurement, change and daily installation of cylinders are eliminated. In operations, cylinders having high cylinder pressure creates a safety issue which is also now addressed with the Nitrogen Generator. With high requirement of Nitrogen for the Nitrogen evaporator and Nitrogen Solvent concentrator, the Nitrogen Generator is a simple solution for tedious logistics, high cost of cylinders and vendor dependency.

PSA Nitrogen Generator

PSA nitrogen generators use a pressure swing adsorption (PSA) process to separate nitrogen from oxygen in the air. PSA Nitrogen Generator uses two towers filled with carbon molecular sieve (CMS). The "online" tower is filled with compressed air that flows through the CMS. Nitrogen passes through the CMS while oxygen and other trace gases are absorbed. Once a pre-set time has passed, the on-line tower automatically switches to regenerative mode, venting contaminants. In contrast to ordinary activated carbon, carbon molecular sieve has a much smaller range of pore openings. Nitrogen molecules are too large to enter the CMS, so oxygen penetrates the pores and we get pure Nitrogen.

Our nitrogen generators are delivered as complete systems, complete with air filters and automatic controls to hook up to a compressed air supply. Start up your PSA Nitrogen Generator by switching it on, and you're ready to start. Also, maintenance is easy. PSA Nitrogen Generator filters only need to be changed once every six to twelve months, depending on your usage.

Intelligent Control

Our in-house developed software process controller generates the output of Nitrogen by optimising the functions to increase compressor life and reduce running costs over long periods of use.

Switching to Nitrogen Generator is a wise decision

  • Recover your operating expense by investing in your capital.
  • Clean particulate free nitrogen with certified purity.
  • Nitrogen supplied on demand.
  • No dependency on vendors and maintenance man-power.
  • Eliminate periodic logistics of cylinder procurement.

Features of Nitrogen Generator

  • Silent and seamless Nitrogen gas supply to your lab.
  • Compact non-obstructive design with the option of wall-mounting and free up precious space.
  • In-built service features to indicate timely routine maintenance.
  • Automatically switches to standby mode when Nitrogen is not required - thereby reducing wear & tear of the compressor.

Advantages of Nitrogen Generator?

  1. Reduced costs: Nitrogen generators can be a more cost-effective option than buying nitrogen gas from a supplier.
  2. Increased safety: On-site nitrogen generation can help to improve safety by reducing the need for nitrogen gas cylinders, which can be a safety hazard if handled by untrained personnel
  3. Increased convenience: Nitrogen generators can provide a convenient and reliable source of nitrogen gas, which can be used on demand.

Takahe’s Nitrogen Generator Specifications of Variants

N2 Genie-1 N2 Genie-2
Nitrogen generation method PSA PSA
Nitrogen Output 100 to 300 LPM* 300 to 600 LPM*
Pressure 100psi 100psi
Purity > 96% > 96%
Moisture < 100 – 300 ppm < 100 – 300 ppm
Micro Particulates < 0.01u < 0.01u
Control Microprocessor Microprocessor
Display LCD LCD
Electric Requirement 230 V 50 Hz 1 Phase 2 Amp 230 V 50 Hz 1 Phase 2 Amp
(subject to change - refer site requirement during purchase)
WDH 24” 12” 36” WDH 24” 18” 60”
Additional receiver tank based on client requirement (Horizontal/vertical)
Weight 98 Kgs 148 Kgs
* Compressor requirements differ for each of the models.


What makes us different from other Nitrogen Generator companies?

There are several factors that make us different from other Nitrogen Generator. One factor is our experience. We have been designing, manufacturing, and selling Nitrogen Generator for over 4 years. With discussions with our users we have a deep understanding of their needs helping us to provide them with high-quality products and services. Our Nitrogen Generator has a dedicated design team and manufacturing team. We have a strict quality control system and professional testing equipment and we have a strong R&D team.

Another factor that makes us different is our commitment to customer service. We have a team of highly trained and experienced customer service representatives who are available to answer any questions that our customers may have. We also offer a 100% satisfaction guarantee on all of our products and services.

How Much Time Should I Have to Wait For Nitrogen Generator Delivery?

Our Nitrogen Generator are typically ex-stock or delivered within 2-3 weeks for special requirements.
