SpeedoVap HV: High Volume Nitrogen Evaporator

SpeedoVap® HV is a High Volume Nitrogen Evaporator & Concentrator specially designed to evaporate large sample volumes. SpeedoVap HV sample concentrator can evaporate 8-15 samples in a batch. The system has the facility to use interchangeable racks for to accommodate any large volume test tube or beaker to meet requirements of different applications with evaporation volume of 50 mL to 200 mL.

The SpeedoVap® HV Nitrogen Evaporator is mainly used in Environmental and Soil Testing laboratories. Also used for water testing, it finds application in food testing laboratories and Food processing industry.

Like the SpeedoVap LV Nitrogen Evaporator, the SpeedoVap HV works on a micro-processor control that maintains the water bath at the set temperature and the times for the operation. Gas can be turned ON in selected manifolds depending on number of samples. Nitrogen gas is blown through rust resistant stainless steel nozzle manifolds into samples which turn OFF automatically after process is completed. Besides other process and service alarms, the audio alarms indicate when the process is complete.

Applications requiring evaporation to a set volume, Takahe has manufactured one of its kind in India – The SpeedoVap HV Optical End Point Nitrogen Evaporator. For more more details on this product click here

Features

  • Unattended operation for up to 15 samples (number of samples dependent on kind and size of glassware)
  • Different interchangeable racks available for tube sizes
  • Controlled water bath adjustable from ambient to 80 °C
  • Built-in nitrogen regulator
  • LED display for better visibility under fume hood
  • Convenient size—no hood space required
  • Exhaust open to atmosphere or within Fume Hood
  • Easy to use water drain pump

Unique features are

Set programme cannot be changed once process has begun.

Printing and data storage facility available.

Option available: A Combo Evaporator that works for both Low Volume and High Volume applications. Solution offered after checking the feasibility at a nominal cost. You need to purchase only one Nitrogen Evaporator instead of two for different applications.

Technical Specifications

Maximum Number of Samples 15
Max. sample volume 200 mL
Rack Supplied Any one Rack listed based on requirement. (additional racks can be ordered separately)
Water Bath Temperature Ambient to 80 °C.
Timer Range 1 min to 10 hours/indefinite
Gas Supply Requirements

Min. inlet pressure 70 psi

Max. inlet pressure 100 psi

Gas can be turned ‘ON’ for any/ each of three independent manifolds

Gas Regulator and Gas Gauge Range Provided – manually adjustable.
Gas Flow Required 50 LPM
Exhaust In-built , Duct hose provided
Power Requirements 230 VAC at 50 Hz (110 VAC –available on request)
Dimensions (WxDxH) 25" x 14"x 13.25" (63.5 x 35.6 x 33.7 cm)
Net Weight 18 kg
Shipping Weight 25 kg
Technology Vortex technology
Certifications

2004/22/EC Measuring Instruments Directive,

2014/35/EU Low Voltage Directive

2009/105/EC Simple Pressure Vessels.

Gas Control Gas can be turned ‘ON’ for any/ each of three independent manifolds

Test Tubes (Dimensions as per catalogue or availability)

Capacity in mL Dimensions in mm (OD X H)
75 29 X 116 (Conical centrifuge tubes)
100 29 X 135 (Conical centrifuge tubes)
100 25 X 150
125 25 X 200
175 32 X 200
200 38 X 200

Bottles Reagent, Wide Mouth With Screw Cap And Pouring Ring (Borosil)

Capacity in mL Dimensions in mm (OD X H)
25 36 X 70
50 46 X 87
100 56 X 100
250 70 X 138

Beakers, Low Form (Borosil)

Capacity in mL Dimensions in mm (OD X H)
25 35 X 45
50 40 X 58
100 50 X 75
150 55 X 88
250 70 X 95
500 85 X 115
